High carbon cast steel shot for shot blasting, desanding, scale removal, surface cleaning, and preparation of steel castings, forgings, heat-treated parts, steel plate, tube, and structural steel.
Supply statusIn stock
Quote requiredRequest current quote
Available models
Supply and reference pricing remain subject to confirmation in the final quotation.
Product model, supply and order information
Model
Supply
Minimum order
Packaging
S110
IN STOCK
Confirm with sales
We can customize the design according to your packaging requirements.
S130
IN STOCK
Confirm with sales
We can customize the design according to your packaging requirements.
S170
IN STOCK
Confirm with sales
We can customize the design according to your packaging requirements.
S230
IN STOCK
Confirm with sales
We can customize the design according to your packaging requirements.
S280
IN STOCK
Confirm with sales
We can customize the design according to your packaging requirements.
S330
IN STOCK
Confirm with sales
We can customize the design according to your packaging requirements.
S390
IN STOCK
Confirm with sales
We can customize the design according to your packaging requirements.
S460
IN STOCK
Confirm with sales
We can customize the design according to your packaging requirements.
S550
IN STOCK
Confirm with sales
We can customize the design according to your packaging requirements.
S660
IN STOCK
Confirm with sales
We can customize the design according to your packaging requirements.
S780
IN STOCK
Confirm with sales
We can customize the design according to your packaging requirements.
Product detail
Technical and purchasing information
High carbon cast steel shot is a reusable metallic abrasive for shot blasting, blast cleaning, desanding, scale removal, and surface preparation of ferrous workpieces. The particles are nearly spherical, so they transfer energy through repeated impact rather than cutting. That makes shot a good fit for jobs where steady cleaning and broad coverage matter more than creating an aggressive profile.
YUXIN supplies high carbon cast steel shot in SAE sizes from S70 to S1110. Size affects both impact and coverage: larger shot hits harder per particle, while smaller shot covers more area. The right choice depends on workpiece size, starting surface condition, blasting equipment, and the finish you need.
Key Product Characteristics
Near-spherical cast steel abrasive for recyclable shot blasting systems
Nominal hardness: 40–50 HRC
Maximum hardness deviation: ±3 HRC
Density: >7.40 g/cm³
Carbon content: 0.85–1.20%
Silicon content: 0.60–1.20%
Manganese content: 0.40–1.20%
Sulfur: ≤0.05%
Phosphorus: ≤0.05%
Tempered martensitic metallurgical structure with dispersed carbides
Wide SAE size range for different blasting and surface-treatment duties
Technical Data
Item
Specification
Product
High Carbon Cast Steel Shot
Carbon (C)
0.85–1.20%
Silicon (Si)
0.60–1.20%
Manganese (Mn)
0.40–1.20%
Sulfur (S)
≤0.05%
Phosphorus (P)
≤0.05%
Hardness
40–50 HRC
Hardness deviation
Maximum deviation range ±3 HRC
Microstructure
Homogeneous tempered martensitic structure with diffusely distributed carbides; exact metallographic condition is subject to grade and inspection result
In wheel blasting or air blasting, steel shot is thrown at the workpiece at high speed. The round particles strike the surface repeatedly, removing loosely or moderately bonded contaminants like foundry sand, oxide scale, and rust. Since the particles are nearly spherical rather than angular, they work mainly by impact and coverage, not by the stronger cutting action you get from steel grit.
That makes cast steel shot especially useful when stable batch cleaning matters more than cutting a rough profile. Size, hardness, blast speed, exposure time, machine condition, and the operating mix all affect the result.
Application Scope by Shot Size
SS-2.5 to SS-1.7 — Heavy Cleaning
Coarser shot sizes are meant for heavy-duty cleaning of large cast steel parts, large castings, structural steel workpieces, and heavy forgings. Typical jobs include removing surface rust, oxide scale, and tightly stuck process residue.
SS-1.4 to SS-1.0 — Medium and Large Workpieces
These grades suit rust removal, scale removal, pre-coating surface treatment, and general blast cleaning of medium and large castings, forgings, heat-treated workpieces, steel plate, steel tube, and structural steel.
SS-0.8 to SS-0.6 — Small and Medium Components
These sizes give a finer balance between impact and coverage. They work well on smaller castings, forgings, heat-treated parts, plate and pipe components, and other jobs where denser surface coverage is needed.
SS-0.5 to SS-0.3 — Finer Surface Treatment
Finer grades can be used on smaller alloy castings, thin plate, strip steel, and other relatively small workpieces where a finer blasting action is preferred. For stainless steel or aluminum-alloy parts, check ferrous contamination requirements and process compatibility before choosing carbon steel shot.
Internal Size and SAE Grade Mapping
Internal Specification
Approx. Reference Size
SAE Grade
SS-2.5
2.5 mm class
S780
SS-2.0
2.0 mm class
S660
SS-1.7
1.7 mm class
S550
SS-1.4
1.4 mm class
S460
SS-1.2
1.2 mm class
S390
SS-1.0
1.0 mm class
S330
SS-0.8
0.8 mm class
S280
SS-0.6
0.6 mm class
S230
SS-0.5
0.5 mm class
S170
SS-0.3
0.3 mm class
S110
SS-0.2
0.2 mm class
S70
The table above reflects the supplied product data. The size distribution table below covers SS-2.5 to SS-0.2, which corresponds to SAE S780 through S70. YUXIN also offers S930 and S1110, but those sieve distributions are not shown here because they were not included in the supplied table.
Particle Size Distribution
Mesh
Opening (mm)
SS-2.5
SS-2.0
SS-1.7
SS-1.4
SS-1.2
SS-1.0
SS-0.8
SS-0.6
SS-0.5
SS-0.3
SS-0.2
7
2.80
All pass
8
2.36
All pass
10
2.00
85% min
All pass
All pass
12
1.70
97% min
85% min
5% min
All pass
14
1.40
97% min
85% min
5% min
All pass
16
1.18
97% min
85% min
5% min
All pass
18
1.00
96% min
85% min
5% min
All pass
20
0.850
96% min
85% min
10% min
All pass
25
0.710
96% min
85% min
10% min
All pass
30
0.600
96% min
85% min
10% min
All pass
35
0.500
97% min
85% min
10% min
40
0.425
97% min
80% min
45
0.355
90% min
80% min
50
0.300
90% min
Example Third-Party Test Data: S550 Sample
An SGS report dated October 28, 2025 tested one YUXIN S550 steel shot sample for chemical composition, Vickers hardness, and metallographic structure.
Test Item
SGS Result for Tested S550 Sample
C
0.89%
Si
0.69%
Mn
0.73%
S
0.017%
P
0.011%
Core hardness
427–462 HV 0.5
Metallographic structure
Tempered martensite + a small amount of retained austenite + fine granular carbides
These SGS values apply only to the tested S550 sample. They are not guaranteed values for every size or production batch.
Standards and Specification Framework
The product information and previously confirmed documentation reference the following standards for high carbon cast steel shot and related size control:
GB/T 18838.3-2008 — High Carbon Cast Steel Shot and Grit
ISO 11124-3 — High-carbon cast-steel shot and grit
JIS G 5903 — Cast steel shot and grit
SFSA 20-66 — Cast steel abrasive
SAE J827 — Cast Steel Shot
SAE J444 — Cast shot and grit size specifications
Product conformity for a specific order is determined by the agreed specification, applicable standard edition, inspection records, and order documents.
Why Particle Size Matters
Shot size affects both impact energy and coverage. Coarser grades generally suit larger, heavier workpieces or more tightly bonded scale. Finer grades put more impacts on each unit of area, so they work better on smaller parts, thinner sections, and jobs that need a finer finish.
The final result also depends on shot hardness, particle shape, blast speed, equipment condition, exposure time, and the operating mix inside the machine. The same nominal shot size can therefore behave differently under different production conditions.
